Simple Website Background Pattern Generator

In this post I will show you how to create a background image for your website using HTML5 canvas.

With simple JavaScript and HTML5 basic drawing techniques we will create our own website background pattern generator. The images created can be used for the website background just like any other image patterns.



Canvas Drawing Basics

Wouldn’t it be nice if you could create our own website background generator?

I will show you how to do this in only a few lines of code?

With HTML5’s canvas you can draw and then exporting the result as inline image information.

So, in this post I will show you how you can get from an HTML5 canvas to a background image that you can set as a CSS background image for your website. It will be a dynamic background as you can change the image slightly every time you draw it.

Here’s the code that produces the dynamic background. If you press “RERUN” you will see that the pattern will change. Below you will find the code explained.

Create A New Canvas Element Javascript

To use HTML5’s canvas component for drawing you have to first create the canvas element. You can either have the <canvas> tag in your HTML document or you can use JavaScript to create it in memory document.createElement("canvas").

Once created you have to get the 2D context of the canvas which provides means of drawing onto the canvas. So, here’s the basic code you need to create a canvas dynamically in memory and start drawing on it.

<!DOCTYPE html>

<html>
<head>
<script type="text/javascript">
//create the canvas element
var myCanvas = document.createElement("canvas");

//set the canvas width and height
myCanvas.width=100;
myCanvas.height=100;

//get the 2-dimensional drawing context
var ctx = myCanvas.getContext("2d");

//draw stuff using the ctx
.....
</script>
</head>
<body>
.....
</body>
</html>

To quickly go over the code above, you will first notice the DOCTYPE directive which indicates that this is an HTML5 document.

Next we create our canvas element.

Please note that the createElement function will create the canvas element in memory and not in the document, so it will not be visible on the screen (unless you append it somewhere in the document). We also have to set the height and width of the canvas, so I did at 100x100 pixels. In our case this will be enough as we will want to create an image 100x100 pixels which we will use for our dynamic background and we will tile this image.

To actually draw on the canvas we have to retrieve the canvas 2D context. This will allow us to draw things like lines, shape contours, filled shapes, etc.

How to Draw a Canvas Rectangles Seamless Pattern

Ok, let’s start drawing our soon to be dynamic background image.

We will draw a 100×100 pixels image which we will tile on our background, so ideally the pattern will be seamless. So, the easiest thing we can do is to have 10×10 squares of 10×10 pixels each and with various shades of gray.

What we aim for is a dynamic image looking similar to this:

dynamic html5 canvas image

Seamless patterns like this are quite trendy today. They are generically referred to as subtle patterns. Once you become more familiar with canvas drawing you can experiment with different circles, triangles and other shapes instead of the rectangles.

If you just want to use traditional images for your website background, I highly recommend this pack of 90 subtle patterns from Photoshop Supply, perfect for website backgrounds.

simple background patterns

To draw squares filled with a gray color we will use the 2D context to draw a rectangle and then fill that rectangle with the right color. Here’s the code extract for drawing a rectangle:

...
//prepare a rectangle 10x10 pixels
//starting from 0,0 coordinates of the canvas
ctx.rect(0,0,10,10);

//set the color you want to use for filling the rectangle
ctx.fillStyle="#cccccc";

//fill the rectangle
ctx.fill();
...

We will want to draw 100 such rectangles one next to the other to cover the entire canvas of 100×100 pixels. Also, we will want to use different shades of gray, so we will do the following:

  1. create an array to store several gray shades which we will later use to randomly pick from
  2. with an iteration draw the 100 rectangles and fill them with a random shade of gray
...
//first we clear the canvas
ctx.clearRect(0,0,100,100);
//setup the palette array
var grayPalette = ["#aaaaaa","#bbbbbb","#cccccc","#dddddd","#eeeeee"];

//create 10x10 squares
for (i=0;i<10;i++){
 for(j=0;j<10;j++){
  //indicate when starting drawing a rectangle
  ctx.beginPath();
  ctx.rect(0+10*j,0+10*i,10,10);

  //choose a random color from the palette
  var randomColorIndex =
    Math.round(Math.random() * (grayPalette.length-1));
  ctx.fillStyle = grayPalette[randomColorIndex];

  //fill the rectangle with the selected color
  ctx.fill();

  //draw a white border for the rectangle
  ctx.strokeStyle = "#ffffff";
  ctx.stroke();

  //indicating when finished drawing the rectangle
  ctx.closePath();
 }
}
...

How to Set a Random Background Image with CSS & JavaScript

So, we did our drawing on the canvas, the canvas is still in memory. We now have to convert the canvas content to an image that we can use for the dynamic background of our document. The HTML5 canvas component offers the possibility of converting the canvas to URL data.

URL data is a way of representing the image binary data encoded such that you can embed it inline in the document and the browser will render it as an image. To get the canvas background image data we need to use the toDataURL() function. We will use the result of this function as the dynamic background image for the body element. Since CSS only supports a static image for the background image style, we will have to dynamically set the backround-image style property using JavaScript. The code will look something like this:

...
var imageDataURL = myCanvas.toDataURL();
//set the resulting image as the background texture
document.body.style.background =
      "transparent url('"+imageDataURL+"') repeat";

Putting it all together

We now have all we need to create and use our dynamic background. In order to see it work I’ve included the following code in this page so every time you click this link the background will be dynamically changed (update: I have removed this functionality and extended the post with CodePen examples for dynamically changing the background) Here’s the full code needed to set the dynamic background (every time you execute this the background will look different due to the random picking of the squares color):

<!DOCTYPE html>

<html>
<head>
<script type="text/javascript">
//create the canvas element
var myCanvas = document.createElement("canvas");

//set the canvas width and height
myCanvas.width=100;
myCanvas.height=100;

//get the 2-dimensional drawing context
var ctx = myCanvas.getContext("2d");
//first we clear the canvas
ctx.clearRect(0,0,100,100);
//setup the palette array
var grayPalette = ["#aaaaaa","#bbbbbb","#cccccc","#dddddd","#eeeeee"];

//create 10x10 squares
for (i=0;i<10;i++){
 for(j=0;j<10;j++){
  //indicate when starting drawing a rectangle
  ctx.beginPath();
  ctx.rect(0+10*j,0+10*i,10,10);

  //choose a random color from the palette
  var randomColorIndex =
    Math.round(Math.random() * (grayPalette.length-1));
  ctx.fillStyle = grayPalette[randomColorIndex];

  //fill the rectangle with the selected color
  ctx.fill();

  //draw a white border for the rectangle
  ctx.strokeStyle = "#ffffff";
  ctx.stroke();

  //indicating when finished drawing the rectangle
  ctx.closePath();
 }
}

//this will run when the document has finished loading
function setDynamicBackground(){
  //generate the image from the canvas
  var imageDataURL = myCanvas.toDataURL();

  //set the dynamic image as the background
  document.body.style.background =
   "transparent url('"+imageDataURL+"') repeat";
}
</script>
</head>
<body onload="setDynamicBackground()">
.....
</body>
</html>

Congratulations

In this post you have actually learned how to use canvas as a background for body. As you can imagine, you can change the code for generating the background to whatever you want. Hope you enjoyed this post and let me know if you have any remarks or questions.

If you are interested in drawing with JavaScript you should definitely check out this simple piechart example using JavaScript.
